X5-B 2.4-inch Digital Door Viewer Home Smart Doorbell Security Door Peephole Cat Eye
Price:
$ 20.70
Specifications
| Retail Packaging | Paper Box |
|---|---|
| User Manual (Language) | English and Chinese |
| Gross Weight | 0.224kg |
| Volume Weight | 0.191kg |
| Package Length | 19.000cm |
| Package Width | 11.800cm |
| Package Height | 3.800cm |
| Package Weight | 0.200kg |
| With Retail Packaging | Yes |
Product Description
X5-B 2.4-inch Digital Door Viewer Home Smart Doorbell Security Door Peephole Cat Eye
-
300,000 pixel CMOS sensor
-
M7 full glass 200W pixel HD lens
-
Support multiple video formats, maximum support 640*480P
-
With wide dynamic and low illumination capabilities, support for automatic color to black
-
Adopt 32-bit processor and professional video codec chip
-
Automatic shutdown after 15 seconds
-
Support manual image capture
-
2.4 inch TFT LCD display
-
Supports up to 32G high-speed TF memory cards
-
Two power supply modes: 3pcs 1.5V / AAA battery or 5V 1A external power supply
Specification:
| Model |
X5-B |
|
|
Camera Module |
Image sensor |
1/4" CMOS (0308) |
|
Effective pixels |
640(H)x480(V) |
|
|
Minimum illumination |
0.5Lux/F2.0 (chromatic color) |
|
|
0.02Lux/F2.0 (black and white) |
||
|
White balance |
Automatic tracking of white balance |
|
|
Gain control |
automatic |
|
|
Signal to noise ratio |
Greater than 50dB |
|
|
BLC |
automatic |
|
|
Wide dynamic |
YES |
|
|
Electronic shutter |
1/4-1/10,000s |
|
|
Day and night mode |
Filter color to black |
|
|
Focal length |
2.4mm |
|
|
Horizontal viewing angle |
120° |
|
|
Aperture |
F2.0 |
|
|
Features |
Automatic shut-down |
15 seconds |
|
Manual capture |
1 piece |
|
|
Parameter |
Main chip |
Jerry |
|
Indoor unit size |
80mmx80mmx18mm |
|
|
Outdoor machine size |
33mmx33mmx7mm |
|
|
Indoor machine material |
ABS plastic |
|
|
Outdoor machine material |
Zinc alloy |
|
|
LCD screen type |
2.4-inches |
|
|
LCD screen resolution |
240(RGB)*320 |
|
|
TF card |
Maximum support 32G |
|
|
Maximum picture size |
640×480 |
|
|
Stand-by current |
100UA |
|
|
Operating temperature and humidity |
-30°C-65°C(outdoor) / -10°C-50°C(indoor) Humidity is less than 90% |
|
|
Protection level |
IP55 |
|
|
Installation method |
Screw plate |
|
|
Applicable door |
35~110mm |
|
|
For cat eyes |
15~20MM |
|
|
Package Size |
190*117*76mm |
|
|
Host color |
black |
|
|
Accessories |
Screws |
M3*35 2 M3*65 2 M3*85 2 |
|
Mounting base plate |
72mm*52mm*6.5mm |
|
|
TF card |
Capacity 8G (optional) |
|
|
battery |
3 x AAA battery(optional) |
|
Package included:
- 1 x Host
- 1 x Camera
- 1 x Charging Cable
- 6 x Screws
- 1 x Hanging Plate
- 1 x Certificate
- 1 x Service Card
- 1 x English and Chinese User Manual
- Other items not included
