TC64 LCD digital Display Type-C Tester Voltmeter Ammeter Voltage Current Meter Multimeter Battery

Price:
$ 9.28

Free Shipping

For just $ 9.28 , buy TC64 LCD digital Display Type-C Tester Voltmeter Ammeter Voltage Current Meter Multimeter Battery from the wholesale webshop online.

Specifications

Retail Packaging Crystal Box
User Manual (Language) No User Manual
Gross Weight 0.019kg
Volume Weight 0.006kg
Length 6.800cm
Width 2.500cm
Height 1.500cm
Weight 0.017kg
With Retail Packaging Yes

Product Description

TC64 LCD digital Display Type-C Tester Voltmeter Ammeter Voltage Current Meter Multimeter Battery
  • The tester is widely used in the quality inspection of Type-C port 3C digital peripheral products. It is the first choice for digital players and electronic lovers

  • It has many functions: screen rotation, data storage, quick charge recognition, capacity and energy detection, temperature measurement, screen off, precision measurement, wide voltage range and low internal resistance

  • For the detection of recharger, power bank and other charging equipment, a variety of data are displayed on one screen to meet diversified testing requirements

  • Adopts a 0.96 inch IPS HD color LCD display with a 160-degree wide view, high brightness and long service life. Let you see from any angle to appreciate the color bright, exquisite and natural display picture

  • 4 bits precision, higher accuracy, smaller date detection error, more accuracy

  • With the function of power off storage, when the power bank is power off, the capacity and energy data can be stored, which is convenient for subsequent inspection, and convenient for capacity and energy measurement of the power bank

  • Clearly understand the load impedance and current discharge power, better understand the load usage range, usage will be more convenient and faster

  • With thermometers function, freely switch between Celsius and Fahrenheit; and it also can measure the quality of the recharger

  • Exquisite and compact, convenient to carry, with USB cap, dust-proof and fall-proof, more beautiful

Specifications:

  • Model: TC64

  • Display screen: 0.96 Inch color IPS display

  • Voltage measurement range: 3.70-30.00V

  • Voltage measurement resolution: 0.01V

  • Current measurement range: 0-4.000A

  • Current measurement resolution: 0.001A

  • Capacity accumulation range: 0-99999mAh

  • Voltage measurement accuracy: ±(0.8%+4 digits at 25℃)

  • Energy accumulation range: 0-99999mWh 999.99Wh

  • Current measurement accuracy: ±(1%+4 digits, at 25℃)

  • Load impedance range: 1Ω-9999.9Ω

  • Power measurement range: 0-120W

  • Temperature range: 0℃~80℃/32℉~176℉

  • Temperature measurement error: ± 3℃/ ± 6℉

  • Working temperature range: 0~45℃/32℉~113℉

  • Refresh rate: 2Hz

  • Dimensions: 50mmx19mmx9mm

  • Product weight: 7g

  • Quick charge recognition mode:QC2.0, QC3.0, APPLE 2.4A/2.1A/1A/0.5A, Android DCP, Samsung

Package included:

  • 1 x TC64 LCD digital Display Type-C Tester
